Finder Type 41.52 RELAY, 2CO 8A@250VAC FOR USE WITH 38.52 RELAY MODULE

Description

Low profile PCB relays, PCB/Plug-in – 5 mm pinning, 2 pole, CO (nPDT), 8 A, AgNi + Au, DC coil, 9 V, operating from 6.3 to 13.5 V, rated power 0.4 W, resistance 200 Ω, consumption 45 mA, holding voltage 3.6 V, must drop-out voltage 0.9 V, option: Production line 1, version: Flux proof (RT II), ambient temperature from -40 to +85 °C

Available variations:
– Low profile PCB relay, 2 CO 8 A (5.0 mm pitch), suitable for mounting on PCB or 95 Series sockets. Equipped with AC or DC coil. 8 mm, 6 kV (1.2/50 μs) between coil and contacts. Cadmium-free contacts. Flux-proof: RT II standard, (also available in RT III version). Versions compliant with IECEx, ATEX (EX ec nC), HazLoc Class I Div. 2, Groups A, B, C, D – T4.
– Low profile PCB relay, 2 CO 8 A (5.0 mm pitch), suitable for mounting on PCB or 95 Series sockets. Equipped with AC or DC coil. 8 mm, 6 kV (1.2/50 μs) between coil and contacts. Cadmium-free contacts. Flux-proof: RT II standard, (also available in RT III version). Versions compliant with IECEx, ATEX (EX ec nC), HazLoc Class I Div. 2, Groups A, B, C, D – T4.

Available models:

• 41.52-012-DC: RELAY, 2CO 8A@250VAC FOR USE WITH 38.52 RELAY MODULE, 12VDC COIL
• 41.52-024-DC: RELAY, 2CO 8A@250VAC FOR USE WITH 38.52 RELAY MODULE, 24VDC COIL
• 41.52-024DC-5010: RELAY, 2CO 8A@250VAC AU FLASHED, FOR USE WITH 38.52 RELAY MODULE, 24VDC COIL
• 41.52-110-DC: RELAY, 2CO 8A@250VAC FOR USE WITH 38.52 RELAY MODULE, 110VDC COIL
